5HP Tohatsu MFS5DS Short Shaft 4-Stroke Outboard with 12 Litre External Fuel Tank

5HP Tohatsu MFS5DS Short Shaft 4-Stroke Outboard with 12 Litre External Fuel Tank

The Tohatsu 5HP MFS5DS Short Shaft 4-Stroke Outboard is designed to deliver exceptional reliability and performance on the water. Perfect for small boats, dinghies, and tenders, this lightweight and portable engine offers smooth operation, improved fuel efficiency, and a quieter ride. Featuring the latest in marine engineering, Tohatsu’s MFS5DS engine is built to last with user-friendly features and cutting-edge technology.

Key Features & Benefits

Compact and Lightweight Design

• Light and Compact: Ideal for portability, this outboard weighs only 25 kg (55 lbs.), making it easy to store and transport.
• Ergonomically Designed Handles: Features newly designed front and back carrying handles for easier lifting and maneuverability.
• Three Storage Positions: Store the engine in three different positions without worrying about oil spillage. (Refer to Owner's Manual for storage and transportation guidelines.)

Efficient and Smooth Operation

• Industry-Leading Vibration Reduction: Tohatsu’s advanced technology greatly reduces vibration, providing a smoother and more stable ride at all speeds.
• Quiet and Low Emission: Enjoy a quiet and eco-friendly boating experience with ultra-low emissions, EPA and CARB 3-Star rating approved.
• Proven Technology: Built with reliable, proven technology for consistent performance, even in demanding conditions.

Ease of Use and Handling

• Recoil Starter with Larger Reel: Fast and easy manual starting for convenient ignition in all conditions.
• New Longer Tiller Handle (110mm Extension): Provides improved control and a more comfortable grip for the operator.
• Digital CD Ignition: For reliable starting, quicker throttle response, and smoother trolling.
• Shallow Water Drive: Easily navigate shallow waters with enhanced maneuverability.
• 6 Trim Positions: Adjust for optimal performance in different water conditions.

Engine Protection & Durability

• Through-the-Prop Exhaust: Provides a quieter, more enjoyable ride by reducing engine noise.
• Stainless Steel Water Pump Housing: Increases durability and resistance to wear, ensuring longer engine life.
• Thermostatically Controlled Cooling System: Maintains a consistent engine temperature for enhanced reliability.
• Corrosion-Resistant Materials: Constructed with high-grade marine aluminum and zinc-coated internal water passages for superior protection against saltwater corrosion.
• Aluminum Propeller: Built to last, offering durability and reliable performance.

Safety Features

• Low Oil Pressure Indicator: Provides a visual warning if the engine oil pressure is too low.
• Safety Lanyard: An essential safety feature that prevents accidental engine starts.
• Start-in-Gear Protection: Prevents the engine from starting when in gear, reducing the risk of injury or damage.
• Over-Revs Limiter: Protects the engine by limiting excessive engine speed.

Specifications

• Engine Type: 4-Stroke, 1 Cylinder
• Output: 5 PS (3.7 kW)
• Displacement: 123 cc (7.5 cu.in.)
• Bore x Stroke: 59 x 45 mm (2.32 x 1.77 in)
• Starting System: Manual
• Control Type: Tiller Handle
• Gear Shift: Forward, Neutral, Reverse
• Gear Ratio: 2.15:1
• Propeller Selection Range: 6" - 9"
• Transom Height: 15"
• Fuel Type: Unleaded Gasoline (87 Octane)
• Oil Type: NMMA Certified FC-W® 4-Stroke Oil, SAE 10W-30/40 (SF, SG, SH, SJ)
• Oil Capacity: 450 mL (15 fl. oz.)
• Fuel Tank Capacity: 12 Litre External Fuel Tank
• Weight: 25 kg (55 lbs.)
• Alternator Output: Optional 12V, 60W, 5A
• Max. RPM Range: 4,500 - 5,500
• Digital CD Ignition System: Standard
• Start-In-Gear Protection: Standard
• Thermostat Controlled Cooling System: Standard
• Through-the-Prop Exhaust: Standard
• Oil Pressure Warning: Standard
• Shallow Water Drive: Standard

Why Choose the Tohatsu 5HP MFS5DS Outboard?

The Tohatsu MFS5DS outboard motor is engineered for reliability, offering impressive fuel efficiency, quiet operation, and low emissions. Whether you are cruising calm waters or navigating shallow areas, the MFS5DS delivers consistent power and performance. Plus, with advanced features like vibration reduction, a digital ignition system, and an easy-to-start manual system, you can confidently enjoy your time on the water.

Order your Tohatsu 5HP MFS5DS today and experience the ultimate in portable outboard motor performance!
